Specifications
Model M-6 M-9
Max Weight of door Single:120kg, Double:90kg x 2 Single: 150Kg, Double: 120Kg x 2
Door Width Single:700~1,100mm, Double:700~1,100mm x 2
Open/close time Max. 750mm/Sec (Adjustable)
Delay Time (open) 0 ~ 60 Sec
Power Supply AC 110V (Optional) / AC 220V, 50~60Hz
Power Consumption Waiting Mode 10W Waiting Mode 10W
Door operation 80W Door operation 100W
Engine Rated Output 60W DC Motor Rated Output 90W DC Motor
Transmission Port RS-232C (RS-485 : Option)
Handy Terminal Wireless Connectione (Infrared communication)
Driving Type TIMING-BELT DRIVE
Operation Temperature -20░c ~ +45░c



Propen Auto Sliding Door S60/S90   (Korea Product)
